Vortex in superconducting thin-film strips of arbitrary width
- Iowa State University, Ames, IA (United States)
- Ames Laboratory (AMES), Ames, IA (United States)
We report the currents and field distributions of a vortex in a thin superconducting strip of a width W are considered. It is shown that unlike infinite films where the vortex field crosses the film only in one direction (say, from the half-space under the film to the half-space above it), in strips (as well as in finite size film samples of any shape) the field lines go back to the lower half-space not only out of the sample but also through certain strip parts. The strip patches where the magnetic lines 'dive' back to the space under the strip are situated mostly near the strip edges, at the strip and out of it. The magnetic flux through the strip associated with the vortex is shown to be less than the flux quantum and depends on the vortex position. The suppression of the vortex flux is strong in narrow strips with W $$\ll$$ Λ = 2λ2/d where λ is the bulk London penetration depth and d is the film thickness. The vortex energy scales roughly with W/Λ and depends on vortex position.
- Research Organization:
- Ames Laboratory (AMES), Ames, IA (United States)
- Sponsoring Organization:
- USDOE Office of Science (SC), Basic Energy Sciences (BES). Materials Sciences & Engineering Division (MSE)
- Grant/Contract Number:
- AC02-07CH11358
- OSTI ID:
- 2340130
- Report Number(s):
- IS-J--11,313
- Journal Information:
- Superconductor Science and Technology, Journal Name: Superconductor Science and Technology Journal Issue: 5 Vol. 37; ISSN 0953-2048
- Publisher:
- IOP PublishingCopyright Statement
- Country of Publication:
- United States
- Language:
- English
