First-Principles Structural, Mechanical, and Thermodynamic Calculations of the Negative Thermal Expansion Compound Zr2(WO4)(PO4)2

Weck, Philippe F.; Kim, Eunja; Gordon, Margaret Ellen; Greathouse, Jeffery A.; Dingreville, Rémi; Bryan, Charles R.

doi:10.1021/acsomega.8b02456

Title: First-Principles Structural, Mechanical, and Thermodynamic Calculations of the Negative Thermal Expansion Compound Zr₂(WO₄)(PO₄)₂

Journal Article · Tue Nov 20 00:00:00 EST 2018 · ACS Omega

DOI:https://doi.org/10.1021/acsomega.8b02456· OSTI ID:1524214

^[1]; Kim, Eunja ^[2]; Gordon, Margaret Ellen ^[1];

^[1]; Dingreville, Rémi ^[1]; Bryan, Charles R. ^[1]

Sandia National Lab. (SNL-NM), Albuquerque, NM (United States)
Univ. of Nevada Las Vegas, Las Vegas, NV (United States)

The negative thermal expansion (NTE) material Zr₂(WO₄)(PO₄)₂ has been investigated for the first time within the framework of the density functional perturbation theory (DFPT). The structural, mechanical, and thermodynamic properties of this material have been predicted using the Perdew, Burke and Ernzerhof for solid (PBEsol) exchange–correlation functional, which showed superior accuracy over standard functionals in previous computational studies of the NTE material α-ZrW₂O₈. The bulk modulus calculated for Zr₂(WO₄)(PO₄)₂ using the Vinet equation of state at room temperature is K_o = 63.6 GPa, which is in close agreement with the experimental estimate of 61.3(8) at T = 296 K. The computed mean linear coefficient of thermal expansion is –3.1 × 10^–6 K^–1 in the temperature range ~0–70 K, in line with the X-ray diffraction measurements. The mean Grüneisen parameter controlling the thermal expansion of Zr₂(WO₄)(PO₄)₂ is negative below 205 K, with a minimum of –2.1 at 10 K. The calculated standard molar heat capacity and entropy are C_P^o = 287.6 and S^o = 321.9 J·mol^–1·K^–1, respectively. The results reported in this study demonstrate the accuracy of DFPT/PBEsol for assessing or predicting the relationship between structural and thermomechanical properties of NTE materials.

View Accepted Manuscript (DOE)

Cite

Export

Save

Research Organization:: Sandia National Lab. (SNL-NM), Albuquerque, NM (United States)

Sponsoring Organization:: USDOE Office of Nuclear Energy (NE), Fuel Cycle Technologies (NE-5)

Grant/Contract Number:: AC04-94AL85000

OSTI ID:: 1524214

Report Number(s):: SAND-2018-10981J; 668511

Journal Information:: ACS Omega, Vol. 3, Issue 11; ISSN 2470-1343

Publisher:: American Chemical Society (ACS)Copyright Statement

Country of Publication:: United States

Language:: English

Citation Metrics:

Cited by: 8 works

Citation information provided by
Web of Science

References (59)
