A high-order discontinuous Galerkin method with unstructured space–time meshes for two-dimensional compressible flows on domains with large deformations

Wang, Luming; Persson, Per-Olof

doi:10.1016/j.compfluid.2015.05.026

A high-order discontinuous Galerkin method with unstructured space–time meshes for two-dimensional compressible flows on domains with large deformations

Journal Article · Thu Jun 04 00:00:00 EDT 2015 · Computers and Fluids

DOI:https://doi.org/10.1016/j.compfluid.2015.05.026· OSTI ID:1524036

Wang, Luming ^[1]; Persson, Per-Olof ^[1]

Univ. of California, Berkeley, CA (United States)

We introduce a high-order accurate space-time discontinuous Galerkin method for solving two-dimensional compressible flow problems on fully unstructured space-time meshes. The discretization is based on a nodal formulation, with appropriate numerical fluxes for the first and the second-order terms, respectively. The scheme is implicit, and we solve the resulting non-linear systems using a parallel Newton-Krylov solver. The meshes are produced by a mesh moving technique with element connectivity updates, and the corresponding space-time elements are produced directly based on these local operations. To obtain globally conforming tetrahedral meshes, we first derive the required conditions on a prism boundary mesh to allow for a valid local triangulation. Next, we present an efficient algorithm for finding a global mesh that satisfies these conditions. We additionally show how to add and remove mesh nodes, again using local constructs for the space-time mesh. Our approach is demonstrated on a number of test problems, showing the high-order accuracy for model problems, and the ability to solve flow problems on domains with complex large deformations.

View Accepted Manuscript (DOE)

Research Organization:: Lawrence Berkeley National Laboratory (LBNL), Berkeley, CA (United States)

Sponsoring Organization:: USDOE; USDOE Office of Science (SC)

Grant/Contract Number:: AC02-05CH11231

OSTI ID:: 1524036

Alternate ID(s):: OSTI ID: 1245264

Journal Information:: Computers and Fluids, Journal Name: Computers and Fluids Journal Issue: C Vol. 118; ISSN 0045-7930

Publisher:: ElsevierCopyright Statement

Country of Publication:: United States

Language:: English
