Unraveling the Semiconducting/Metallic Discrepancy in Ni3(HITP)2

Foster, Michael E.; Sohlberg, Karl; Allendorf, Mark D.; Talin, A. Alec

doi:10.1021/acs.jpclett.7b03140

Unraveling the Semiconducting/Metallic Discrepancy in Ni₃(HITP)₂

Journal Article · Wed Jan 10 00:00:00 EST 2018 · Journal of Physical Chemistry Letters

DOI:https://doi.org/10.1021/acs.jpclett.7b03140· OSTI ID:1421638

^[1]; Sohlberg, Karl ^[2]; Allendorf, Mark D. ^[1]; ^[1]

Sandia National Lab. (SNL-CA), Livermore, CA (United States)
Drexel Univ., Philadelphia, PA (United States)

Here, Ni₃(2,3,6,7,10,11-hexaiminotriphenylene)₂ is a π-stacked layered metal–organic framework material with extended π-conjugation that is analogous to graphene. Published experimental results indicate that the material is semiconducting, but all theoretical studies to date predict the bulk material to be metallic. Given that previous experimental work was carried out on specimens containing complex nanocrystalline microstructures and the tendency for internal interfaces to introduce transport barriers, we apply DFT to investigate the influence of internal interface defects on the electronic structure of Ni₃(HITP)₂. The results show that interface defects can introduce a transport barrier by breaking the π-conjugation and/or decreasing the dispersion of the electronic bands near the Fermi level. We demonstrate that the presence of defects can open a small gap, in the range of 15–200 meV, which is consistent with the experimentally inferred hopping barrier.

View Accepted Manuscript (DOE)

Research Organization:: Sandia National Laboratories (SNL-NM), Albuquerque, NM (United States)

Sponsoring Organization:: USDOE National Nuclear Security Administration (NNSA)

Grant/Contract Number:: AC04-94AL85000

OSTI ID:: 1421638

Report Number(s):: SAND--2017-12553J; 658910

Journal Information:: Journal of Physical Chemistry Letters, Journal Name: Journal of Physical Chemistry Letters Journal Issue: 3 Vol. 9; ISSN 1948-7185

Publisher:: American Chemical SocietyCopyright Statement

Country of Publication:: United States

Language:: English

References (24)

C RYSTAL14 : A program for the ab initio investigation of crystalline solids Dovesi, Roberto; Orlando, Roberto; Erba, Alessandro International Journal of Quantum Chemistry, Vol. 114, Issue 19 https://doi.org/10.1002/qua.24658	journal	March 2014
Conduction in glasses containing transition metal ions Mott, N. F. Journal of Non-Crystalline Solids, Vol. 1, Issue 1 https://doi.org/10.1016/0022-3093(68)90002-1	journal	December 1968
A Microporous and Naturally Nanostructured Thermoelectric Metal-Organic Framework with Ultralow Thermal Conductivity Sun, Lei; Liao, Bolin; Sheberla, Dennis Joule, Vol. 1, Issue 1 https://doi.org/10.1016/j.joule.2017.07.018	journal	September 2017
Chain-Assisted Charge Transport in Semicrystalline Conjugated Polymers Conchuir, B. O.; Tarantini, C.; McNeill, C. R. The Journal of Physical Chemistry C, Vol. 120, Issue 27 https://doi.org/10.1021/acs.jpcc.6b04714	journal	June 2016
Proposed Modification of the Graphene Analogue Ni ₃ (HITP) ₂ To Yield a Semiconducting Material Foster, Michael E.; Sohlberg, Karl; Spataru, Catalin D. The Journal of Physical Chemistry C, Vol. 120, Issue 27 https://doi.org/10.1021/acs.jpcc.6b05746	journal	June 2016
High Electrical Conductivity in Ni ₃ (2,3,6,7,10,11-hexaiminotriphenylene) ₂ , a Semiconducting Metal–Organic Graphene Analogue Sheberla, Dennis; Sun, Lei; Blood-Forsythe, Martin A. Journal of the American Chemical Society, Vol. 136, Issue 25 https://doi.org/10.1021/ja502765n	journal	April 2014
Redox Control and High Conductivity of Nickel Bis(dithiolene) Complex π-Nanosheet: A Potential Organic Two-Dimensional Topological Insulator Kambe, Tetsuya; Sakamoto, Ryota; Kusamoto, Tetsuro Journal of the American Chemical Society, Vol. 136, Issue 41 https://doi.org/10.1021/ja507619d	journal	October 2014
Porous Field-Effect Transistors Based on a Semiconductive Metal–Organic Framework Wu, Guodong; Huang, Jiahong; Zang, Ying Journal of the American Chemical Society, Vol. 139, Issue 4 https://doi.org/10.1021/jacs.6b08511	journal	November 2016
Metallic Conductivity in a Two-Dimensional Cobalt Dithiolene Metal–Organic Framework Clough, Andrew J.; Skelton, Jonathan M.; Downes, Courtney A. Journal of the American Chemical Society, Vol. 139, Issue 31 https://doi.org/10.1021/jacs.7b05742	journal	July 2017
Predictions of Hole Mobilities in Oligoacene Organic Semiconductors from Quantum Mechanical Calculations ^† Deng, Wei-Qiao; Goddard, William A. The Journal of Physical Chemistry B, Vol. 108, Issue 25 https://doi.org/10.1021/jp0495848	journal	June 2004
Definitive Band Gaps for Single-Wall Carbon Nanotubes Matsuda, Yuki; Tahir-Kheli, Jamil; Goddard, William A. The Journal of Physical Chemistry Letters, Vol. 1, Issue 19 https://doi.org/10.1021/jz100889u	journal	September 2010
Near room-temperature synthesis of transfer-free graphene films Kwak, Jinsung; Chu, Jae Hwan; Choi, Jae-Kyung Nature Communications, Vol. 3, Issue 1 https://doi.org/10.1038/ncomms1650	journal	January 2012
Solid-source growth and atomic-scale characterization of graphene on Ag(111) Kiraly, Brian; Iski, Erin V.; Mannix, Andrew J. Nature Communications, Vol. 4, Issue 1 https://doi.org/10.1038/ncomms3804	journal	November 2013
Metal–organic Kagome lattices M ₃ (2,3,6,7,10,11-hexaiminotriphenylene) ₂ (M = Ni and Cu): from semiconducting to metallic by metal substitution Chen, Shuang; Dai, Jun; Zeng, Xiao Cheng Physical Chemistry Chemical Physics, Vol. 17, Issue 8 https://doi.org/10.1039/C4CP05328A	journal	January 2015
Grain boundary barrier breakdown in niobium donor doped strontium titanate using in situ electron holography Johnson, Kevin D.; Dravid, Vinayak P. Applied Physics Letters, Vol. 74, Issue 4 https://doi.org/10.1063/1.123184	journal	January 1999
Graphene synthesis by ion implantation Garaj, Slaven; Hubbard, William; Golovchenko, J. A. Applied Physics Letters, Vol. 97, Issue 18 https://doi.org/10.1063/1.3507287	journal	November 2010
Corrections to density-functional theory band gaps Johnson, Kurt A.; Ashcroft, N. W. Physical Review B, Vol. 58, Issue 23 https://doi.org/10.1103/PhysRevB.58.15548	journal	December 1998
Quantum spin Hall and Z 2 metallic states in an organic material Zhao, Bao; Zhang, Jiayong; Feng, Wanxiang Physical Review B, Vol. 90, Issue 20 https://doi.org/10.1103/PhysRevB.90.201403	journal	November 2014
Migration and Localization of Metal Atoms on Strained Graphene Cretu, Ovidiu; Krasheninnikov, Arkady V.; Rodríguez-Manzo, Julio A. Physical Review Letters, Vol. 105, Issue 19 https://doi.org/10.1103/PhysRevLett.105.196102	journal	November 2010
Nonstoichiometry and the Electrical Activity of Grain Boundaries in SrTiO 3 Kim, Miyoung; Duscher, Gerd; Browning, Nigel D. Physical Review Letters, Vol. 86, Issue 18 https://doi.org/10.1103/PhysRevLett.86.4056	journal	April 2001
Intrinsic Charge Transport on the Surface of Organic Semiconductors Podzorov, V.; Menard, E.; Borissov, A. Physical Review Letters, Vol. 93, Issue 8, Article No. 086602 https://doi.org/10.1103/PhysRevLett.93.086602	journal	August 2004
Electric Field Effect in Atomically Thin Carbon Films Novoselov, K. S. Science, Vol. 306, Issue 5696, p. 666-669 https://doi.org/10.1126/science.1102896	journal	October 2004
Thermoelectric Properties of 2D Ni ₃ (HITP) ₂ and 3D Cu ₃ (BTC) ₂ MOFs: First-Principles Studies He, Yuping; Talin, A. Alec; Allendorf, Mark D. ECS Transactions, Vol. 80, Issue 5 https://doi.org/10.1149/08005.0047ecst	journal	August 2017
Models for the Temperature and Gas Partial Pressure Dependence of Conductance Wexler, RobertB.; Sohlberg, Karl Reviews in Theoretical Science, Vol. 4, Issue 2 https://doi.org/10.1166/rits.2016.1051	journal	June 2016

Cited By (9)

Proximity Effect in Crystalline Framework Materials: Stacking‐Induced Functionality in MOFs and COFs Kuc, Agnieszka; Springer, Maximilian A.; Batra, Kamal Advanced Functional Materials, Vol. 30, Issue 41 https://doi.org/10.1002/adfm.201908004	journal	February 2020
Origin of the Chemiresistive Response of Ultrathin Films of Conductive Metal–Organic Frameworks Rubio‐Giménez, Víctor; Almora‐Barrios, Neyvis; Escorcia‐Ariza, Garin Angewandte Chemie, Vol. 130, Issue 46 https://doi.org/10.1002/ange.201808242	journal	October 2018
Origin of the Chemiresistive Response of Ultrathin Films of Conductive Metal–Organic Frameworks Rubio‐Giménez, Víctor; Almora‐Barrios, Neyvis; Escorcia‐Ariza, Garin Angewandte Chemie International Edition, Vol. 57, Issue 46 https://doi.org/10.1002/anie.201808242	journal	November 2018
A Highly Conductive MOF of Graphene Analogue Ni ₃ (HITP) ₂ as a Sulfur Host for High‐Performance Lithium–Sulfur Batteries Cai, Dong; Lu, Mengjie; Li, La Small, Vol. 15, Issue 44 https://doi.org/10.1002/smll.201902605	journal	September 2019
Formation of the layered conductive magnet CrCl2(pyrazine)2 through redox-active coordination chemistry Pedersen, Kasper S.; Perlepe, Panagiota; Aubrey, Michael L. Nature Chemistry, Vol. 10, Issue 10 https://doi.org/10.1038/s41557-018-0107-7	journal	September 2018
Efficient and tunable one-dimensional charge transport in layered lanthanide metal–organic frameworks Skorupskii, Grigorii; Trump, Benjamin A.; Kasel, Thomas W. Nature Chemistry, Vol. 12, Issue 2 https://doi.org/10.1038/s41557-019-0372-0	journal	November 2019
Conductive two-dimensional metal–organic frameworks as multifunctional materials Ko, Michael; Mendecki, Lukasz; Mirica, Katherine A. Chemical Communications, Vol. 54, Issue 57 https://doi.org/10.1039/c8cc02871k	journal	January 2018
Pressure-induced metallicity and piezoreductive transition of metal-centres in conductive 2-dimensional metal–organic frameworks Le, Khoa N.; Hendon, Christopher H. Physical Chemistry Chemical Physics, Vol. 21, Issue 46 https://doi.org/10.1039/c9cp04797b	journal	January 2019
Proximity Effect in Crystalline Framework Materials: Stacking‐Induced Functionality in MOFs and COFs Kuc, Agnieszka; Springer, Maximilian A.; Batra, Kamal Wiley-VCH Verlag https://doi.org/10.5445/ir/1000105891	text	January 2020

Figures / Tables (6)
