Metasurface polarization splitter

Slovick, Brian A.; Zhou, You; Yu, Zhi Gang; Kravchenko, Ivan I.; Briggs, Dayrl P.; Moitra, Parikshit; Krishnamurthy, Srini; Valentine, Jason

doi:10.1098/rsta.2016.0072

Metasurface polarization splitter

Journal Article · Sun Feb 19 23:00:00 EST 2017 · Philosophical Transactions of the Royal Society. A, Mathematical, Physical and Engineering Sciences

DOI:https://doi.org/10.1098/rsta.2016.0072· OSTI ID:1351760

Slovick, Brian A. ^[1]; Zhou, You ^[2]; Yu, Zhi Gang ^[3]; Kravchenko, Ivan I. ^[4]; Briggs, Dayrl P. ^[4]; Moitra, Parikshit ^[5]; Krishnamurthy, Srini ^[1]; ^[2]

SRI International, Menlo Park, CA (United States)
Vanderbilt Univ., Nashville, TN (United States)
Washington State Univ., Pullman, WA (United States)
Oak Ridge National Lab. (ORNL), Oak Ridge, TN (United States)
Univ. of Southampton, Southampton (United Kingdom)

Polarization beam splitters, devices that separate the two orthogonal polarizations of light into different propagation directions, are among the most ubiquitous optical elements. However, traditionally polarization splitters rely on bulky optical materials, while emerging optoelectronic and photonic circuits require compact, chip-scale polarization splitters. Here, we show that a rectangular lattice of cylindrical silicon Mie resonators functions as a polarization splitter, efficiently reflecting one polarization while transmitting the other. We show that the polarization splitting arises from the anisotropic permittivity and permeability of the metasurface due to the twofold rotational symmetry of the rectangular unit cell. Lastly, the high polarization efficiency, low loss and low profile make these metasurface polarization splitters ideally suited for monolithic integration with optoelectronic and photonic circuits.
